Imaging Cameras

USB CMOS Cameras
We offers a wide range of imaging cameras (CMOS) for vision applications. These cameras are of high quality, and provide clear and sharp images for vision and imaging applications. All our cameras are USB cameras, which can be connected to an USB port of your PC or laptop.

We offer cameras with different pixel capacity. Please browse through our models below:

MD30 - 3 MP CMOS Camera	MD50 - 5 MP CMOS Camera
MD90 - 9 MP CMOS Camera	MDX4 - 14 MP CMOS Camera

MD30 - 3 MP CMOS Cameras

Key parameters:

Ask for Price

3.0 megapixels, progressive scanning CMOS sensor.
No compression, no interpolation.
Support still image capture(JPG,BMP)
15 fps at 1600x1200 pixel; 30 fps at 800x600 pixels.
USB2.0 interface, up to 480MPS, external power no need.
Standard C-MOUNT.

Feature:

Interfaced to a computer via USB2.0 technology for rapid image download
3.0 megapixels with progressive scanning CMOS image sensor
Plug-to-use, suitable for shooting of any standard biological, stereo and metallurgical microscopes
Ease of operation; only take 5 minutes to master the friendly software.
Standard C-Mount makes connection to any microscope easy. Macro lens setups are also supported
Fully integrated package with digital camera and imaging software for managing your imaging work flow.
Data can be shared, stored and edit, real-time preview function offers you the greatest experience with the microscope.
Video taping is available, simple to store and transfer when compression mode is selected

MD30 Camera Specifications

Sensor	1/ 2" CMOS	Sensitivity	1.0 V/ lux-sec (550nm)
Resolution	2048×1563(10bit)	Data Interface	USB2.0 (480 Mbit / sec)
Pixels Size	3.2µm×3.2µm	Power Supply	DC 5V ± 5%
Frame Rate	12fps@2048×1536	Electricity	˜200 mA
Frame Rate	30 fps@640 ×480	White Balance	Manual/Auto one-touch
Shutter	Electronic	Exposure control	10µs–32ms,Auto exposure
S/N Ratio	43 dB	Software	Display/Film/Video
Scanning Mode	Progressive scanning	Operating Temp	0°C ~ 60°C

Yes! I am Interested

MD50 - 5 MP CMOS Cameras

Key parameters:

Ask for Price

5.0 megapixels, progressive scanning CMOS sensor
No compression, no interpolation.
Support still image capture(JPG,BMP)
USB2.0 interface, up to 480MPS, external power no need.
Standard C-MOUNT, durable aluminum alloy casing

Feature:

5.0 megapixels MSHOT MD50 uses a 2592x1944 pixel color CMOS
Interfaced to a computer via USB2.0 technology for rapid image download.
It uses a 12-bit analog to digital converter, recording subtle color differences important for accurate color reproduction. The result is images with outstanding color and fine detail.
Plug-to-use, no need for extra power
Easy store and recall feature allows the user to retrieve the same settings for further analysis or comparison

MD50 Camera Specifications

Sensor	1/2.5?CMOS	Sensitivity	0.53 V/lux-sec (550nm)
Resolution	2592x1944(12bit)	Data Interface	USB2.0 (480 Mbit / sec)
Pixels Size	2.2µm x 2.2µm	Power Supply	DC 5V ± 5%
Frame Rate	5fps@2592x1944	Electricity	˜200 mA
Frame Rate	19fps@640x480	White Balance	Manual/Auto one-touch
Shutter	Electronic	Exposure control	10µs–32ms,Auto exposure
S/N Ratio	40.5dB	Software	Display/Film/Video
Scanning Mode	Progressive scanning	Operating Temp	-30°C ~ 70°C

Yes! I am Interested

MD90 - 9 MP CMOS Cameras

Key parameters:

Ask for Price

9.0 megapixels, progressive scanning CMOS sensor.
No compression, no interpolation.
Support still image capture (JPG, BMP)
USB2.0 interface, up to 480MPS, external power no need.
Standard C-MOUNT, durable aluminum alloy casing

Feature:

9.0 megapixels, providing excellent high-quality and high-resolution images
USB2.0 design makes it easy to realize the connections between PC and the camera.
The application software interface is much simple too.
Standard C-Mount makes connection to any standard trinocular microscope, such as stereozoom microscope, metallograph microscope.
Easy-to-operate with strong compatibility operating software. Auto control of exposure, contrast, brightness, saturation, image size etc.
Support video functions, easy to preserve and transfer. Added a projector, MD10 can be used to teaching and presentation too

MD50 Camera Specifications

Sensor	1/ 2.3?CMOS	Sensitivity	0.44 V/lux-sec (550nm)
Resolution	3488x2616(12bit)	Data Interface	USB2.0 (480 Mbit / sec)
Pixels Size	1.75µm x 1.75µm	Power Supply	DC 5V ± 5%
Frame Rate	3fps @ 3488 x 2616	Electricity	˜200 mA
Frame Rate	30 fps@640x480	White Balance	Manual/Auto
Shutter	Electronic	Exposure control	10µs–32ms,Auto exposure
S/N Ratio	40.5dB	Software	Display/Film/Video
Scanning Mode	Progressive scanning	Operating Temp	-30°C ~ 70°C

Yes! I am Interested

MDX4 - 14 MP CMOS Cameras

Feature:

14.0 megapixels, progressive scanning CMOS sensor.
No compression, no interpolation.
Support still image capture (JPG, BMP) and dynamic AVI/MPEG4 image capture (optical)
USB2.0 interface, up to 480MPS, makes it easy to realize the connections between PC and the camera.
Easy-to-operate with strong compatibility operating the software.
Auto control of exposure, contrast, brightness, saturation, image size etc.
Offer excellent high-quality and high-resolution images.
Plug-and-use, external power not needed, supports Windows 2000/7 and XP
Standard C-Mount makes the connection to any standard trinocular microscope, such as stereo zoom microscope, metallography microscope.
Aluminum alloy shell, elegant, durable, heat eliminable

MDX4 Camera Specifications

Sensor	1/2.3" color CMOS, 14.0 megapixels	Sensitivity	0.724 V/lux-sec (550nm)
Resolution	4608X3288(12bit)	Spectral Response	400nm~1000nm
Pixels Size	1.4µm*1.4µm	Data Interface	USB2.0 (480 Mbit / sec)
Frame Rate	2fps @ 4384 x 3288	Power Supply	DC 5V ± 5%
	7fps@2048x1536	Electricity	˜200 mA
	10fps@1280x960
	16fps@1024x768
	18fps@640x480
Shutter	Electronic	White Balance	Manual/Auto
S/N Ratio	35.5dB	Exposure control	10µ s– 800ms, Auto exposure
Scanning Mode	Progressive scanning	Software	Display/Film/Video
Operating Temp.	-30° C ~ 70° C	Application	microscope imaging, general image capturing, macrophotography, etc.

Yes! I am Interested
